Technical Details
Manufacturer: Joslyn
Pumped Liquid Type: Thin, non-explosive liquids, not containing solid particles or fibers.
Temperature Range:
- Standard Design → -15°C to +90°C
- Hot water Design → -15°C to +120°C
ENCLOSURE:
- V18 ≤ 4 kW
- V1 ≥ 5.5 kW
Voltage:
- 50 Hz → 3 x 200 - 220 / 346 - 380 V, ±10%
3 x 220 - 240 / 380 - 415 V
3 x 380 - 415 V
1 x 220 - 230 / 240 V
- 60 Hz → 3 x 460 / 220 V
Insulation Class : F
Enclosure IP Ration: IP55 or IP 44 & IP 54 – on request
Efficiency Class : Eff.2 or Eff.1 – on request
Ambient Temperature:
- Standard → 40°C
- High → 50°C with 0.95 & 55°C with 0.92 derating factors
Altitude:
- Standard → 1,000 m
- High → 2,250 m with 0.95 & 3,500 m with 0.88 derating factors
